The outputs

 employ switching transistors,  have a rated load capability of 2 A and  are overload and short–circuit proof.

The module is mounted with screws. There are bore holes available for both mounting on a rear wall or on a horizontal surface.

The CS31 system bus connection is electrically isolated from remaining module components.

The module offers diagnosis functions (see chapter ”Diagnosis and displays”).

Displays and connections at module housing

16 yellow LEDs for displaying the signal statuses of the outputs

LEDs ”Bus Error”, ”Overload” and ”Supply” indicating of operating conditions and errors (see section ”Diagnosis and displays”) CS31 bus connector (input)

CS31 bus connector (output)

16 connectors for the outputs

PG11 cable gland for the 24 V DC power supply

The terminals for 24 V DC and PE are located under a removable cover. It is accessible from the top of the module. The DIL switch for setting the module address is also under the cover.

Labelling fields

Bore holes for mounting (see also ”Dimensioned drawing” at the end of this description)

Electrical connection

The following figure shows all details necessary for the electrical connection.
