2VAA008150R320 ABB H&B Contronic

2VAA008150R320    ABB H&B Contronic

Fault indication

The led's indicate the following :

Led 0 : "Unit error"

Led 1 : "Bus error"

Led 5 : "Short-circuit or overload"

The status of an input channel is shown by :

Led 7 : "Input"

If an error occurs the red led error is On (see Chapter 9, Volume 2 «In case of failure»).

Intended purpose

The binary output module ICPO 16 H1 is a remote module on the CS31 system bus. It has 16 binary channels with the following features:

 Housing and termination system according to IP65 degree of protection

 The CS31 bus line is looped through from module to module. For this purpose, the module has two bus connectors as bus input and bus output.

 Each output has its own connector and thus can be unplugged individually.

 The 24 V DC supply voltage is connected via screw–type terminals inside the module housing.
