2VAA008152R325 ABB H&B Contronic
From: | author:kongjiang | Release :2021-08-11 | 623 view: | Share:

2VAA008152R325    ABB H&B Contronic

Technical data ICPO 16 H1

In general, the technical system data listed in volume 2 of the system description ABB Procontic CS31 are valid for all modules and central units. Additional data or data which are different from the system data are listed as follows.

Connectors and terminals

Power supply 24 V DC Screw–type terminals 2.5 mm2 inside the housing,

PG11 gland for cable

CS31 bus line 2 x 4–pole M12 connector (female)

Outputs

Power supply 16 x 5–pole M12 connector (female)

Rated supply voltage L+ 24 V DC

Current consumption, without output loads max. 0.1 A

Max. supply current (incl. output loads) 20 A

Conductor cross section max. 2.5 mm2

Internal fuse (under the cover)

Outputs 32 A, slow, 6 x 32 mm

Number of outputs per module 16 (overload and short–circuit proof, electrically not isolated)

Signal level of the outputs, signal 1 like L+, max. transistor saturation voltage 0.5 V

Leakage current signal 0

Output load capability < 10 µA

max. current per output 2 A continuously

lamp load per output max. 50 W

total output current (all outputs together) max. 20 A

Switching frequency with inductive load max. 2 Hz

with resistive load max. 100 Hz

Short–circuit and overload protection electronically

Switch–off delay in case of a short–circuit ca. 150 µs

Short–circuit indication

Limitation of output voltage, yes, with a red LED

if an inductive load is switched off by an integrated suppressor diode

switch–off peak

3BUR000740R1

SA168K09 RM500V1 Power 230V/25A/2,7m

3BUR000741R1

SA162K07 Power Supply for I/O Subrack 2

3BUR000742R1

SA168K10 Power Supply for I/O Subrack 2

3BUR000743R1

Power Supply for CPU Subrack and I/O

3BUR000744R1

Power Supply for I/O Subrack 2 and 3

3BUR000745R1

DSSB170K08 Energy Reserve 24VDC for CPU

3BUR000746R1

DSSB170K09 Energy Reserve 24VDC for I/O

3BUR000846R1

SA167K11 RM500V1 Power 120V/25A/1,4m

3BUR000847R1

SA167K12 RM500V1 Red Power 120V/25A/1,4m

3BUR000848R1

SA168K11 RM500V1 Power 230V/25A/1,4m

3BUR000849R1

SA168K12 RM500V1 Red Power 230V/25A/1,4m
