8VZZ004869L0325    ABB H&B Contronic

The available configuration for each input :

– delay

– open circuit detection

The available configuration for each output :

– open circuit detection

A channel can be used for an input or an output, depending upon the user program.

Note :

The inputs/outputs are configurated in outputs when the DIP switch N° 1 on the plug-in base ECZ is ON. This allows to use again the address coded for an input unit.

● Fault indication

The led's indicate the following :

Led 0 : "Unit error"

Led 1 : "Bus error"

Led 3 : "Cut wire"

Led 4 : "Overload"

Led 5 : "Short Circuit"

The status of an input channel is shown by : Led 6 : "Output"

Led 7 : "Input"

If an error occurs the red led error is On (see Chapter 9, Volume 2 «In case of failure»).
