8VZZ004864L0325    ABB H&B Contronic

Technical data ICDG 32 L1

In general, the technical system data listed in volume 2 of the system description ABB Procontic CS31 are valid for all modules and central units. Additional data or data which are different from the system data are listed as follows.

General data of the module

Admissible temperature range, module in operation 0...65 °C

Rated supply voltage 24 V DC

Rated signal voltage at inputs and outputs

Max. current consumption, outputs unloaded0.15 A

Max. total output current 4.0 A 24 V DC

Max. rated loadability for the supply terminals

Max. power dissipation in the module, 4.0 A

outputs unloaded

Max. power dissipation in the module 5 W

outputs under load 10 W

Overvoltage category

Buffered voltage interruption time II according to IEC 65 A

for the processor part > 10 ms
