IC698ACC701 Lithium Battery pack

PACSystems* RX7i Controller

Performance – Delivering on the

Demands of Your Most Advanced

Applications

• Pentium® CPUs for your every need, from

Celeron 300Mhz to M Class 1.8Ghz

• VME64 Backplane provides up to four

times the bandwidth of existing Series

90*-70 systems

• 10/100 Ethernet built into the CPU, with

easy cabling RJ-45 dual ports connected

through an auto-sensing switch — no need

for additional switches or hubs rack to rack

• Up to 64MB memory for fast execution,

storage of the complete program with all

documentation (including Excel, Word, PDF

and DXF files) — all in one CPU

• Object Oriented programming through

IEC languages including C for fast executing,

standards based applications

• Integration of Control Memory Xchange,

a high speed global memory over a fiber

network — like having a networked drive

everyone can see and share

• High capacity power supplies (100W and

350W) to reduce the requirement for an

external supply

Productivity – Maximizing Efficiency

of Design and Operation

• One common environment for configuring,

programming, commissioning, and

maintaining your application with Proficy*

Machine Edition

• One tool for Control, View and Motion program

development

• System Management with Manager provides

Version Control, Security Access, and

Audit Trail

• Embed Proficy Historian or other tools typically

requiring a separate computer for

maximum productivity

With our CPX family of CPUs, the Series 90-70

offers more for your automation dollar—more

computing power, more memory for your

applications, and more communications and

redundancy capabilities. And it provides

increased flexibility for a variety of

applications due to a wide range of isolated

and high-density VME analog I/O modules.

Open Architecture

Based on the VME-bus standard, the Series

90-70 can be used with thousands of boards

produced by hundreds of different manufacturers

to build a solution that meets your

exact needs. These include links to drives

and drive systems, servo motor controllers,

embedded solutions for vision systems and

bus-to-bus interface modules, as well as a

variety of modules available from GE (see

accompanying table).

Various Degrees of Redundancy

Combining the Series 90-70 with the

advanced functionality of Genius* I/O,

GE Genius Modular Redundancy (GMR)

systems and Hot Standby systems can

provide as much or as little redundancy

as you need for your critical applications.

• The versatility and strength of the GMR

system make it an ideal choice for rigorous

emergency shutdown and human life protection

systems. It has a class 6 TÜV rating.

• Based on three isolated PLCs and extensive

diagnostics, the GMR triple modular

redundancy system uses two-out-of-three

voting to provide high reliability and errorfree

operation.

• CPU Genius Redundancy (CGR) systems

achieve enhanced hot standby CPU redundancy

by connecting two power supplies

and two CGR CPUs to one or more Genius

I/O networks.

Flexible Communications Options

The Series 90-70 offers a wide variety of

communications options, including Ethernet

TCP/IP, reflective memory, Genius LAN,

and serial communications modules that

enable precise solutions using off-the-shelf

components. It is an ideal candidate for

acting as your factory-floor server, collecting

data and seamlessly integrating it with the

ERP system.

------------------------------------------------------------------------------------------------

Simplex Controllers

IC697CPU731 CPU, 512 Discrete I/O, 32K Memory, 12 MHz Processor, 1 serial port

IC697CPX928 CPU, 12K Discrete I/O, 6 Meg Memory, 96 MHz Processor, 3 serial ports

IC697CPX772 CPU, 2K Discrete I/O, 512K Memory, 96 MHz Processor, 3 serial ports

IC697CPX935 CPU, 12K Discrete I/O, 1 Meg fast access Memory, 96 MHz Processor,

3 serial ports

IC697CPX782 CPU, 12K Discrete I/O, 1 Meg Memory, 96 MHz Processor, 3 serial ports

Hot Standby CPUs IC697CGR772 CPU, 2K Discrete I/O, 512K Memory, 96 MHz Processor, 3 serial ports

 IC697CGR935 CPU, 12K Discrete I/O, 1Meg Memory, 96 MHz Processor, 3 serial ports

Critical Control CPU IC697CPM790 CPU, 2K Discrete I/O, 1 Meg Memory, 64 MHz Processor. Triplex Voted I/O

IC697MDL240 120 Vac Isolated Input (16 Points)

IC697MDL240RR 120 Vac Isolated Input (16 Points)

IC697MDL241 240 Vac Isolated Input (16 Points)

IC697MDL241RR 240 Vac Isolated Input (16 Points)

IC697MDL250 120 Vac Input (32 Points)

IC697MDL250RR 120 Vac Input (32 Points)

IC697MDL251 120 Vac Input (16 Points) Non-isolated

IC697MDL251RR 120 Vac Input (16 Points) Non-isolated

IC697MDL252 12 Vac Input (32 Points)

IC697MDL252RR 12 Vac Input (32 Points)

IC697MDL253 24 Vac Input (32 Points)

IC697MDL253RR 24 Vac Input (32 Points)

IC697MDL254 48 Vac Input (32 Points)

IC697MDL254RR 48 Vac Input (32 Points)

IC697MDL340 120 Vac Output, 2 Amp (16 Points)

IC697MDL340RR 120 Vac Output, 2 Amp (16 Points)

IC697MDL341 120/240 Vac Isolated Output, 2 Amp (12 Points)

IC697MDL341RR 120/240 Vac Isolated Output, 2 Amp (12 Points)

IC697MDL350 120 Vac Output, 0.5 Amp (32 Points)

IC697MDL350RR 120 Vac Output, 05 Amp (32 Points)

IC697MDL640 125 Vdc Input (16 Points)

IC697MDL640RR 125 Vdc Input (16 Points)

IC697MDL650RR 24 Vdc Input, Positive Logic (32 Points)

IC697MDL651 5 Vdc (TTL) Input (32 Points)

IC697MDL651RR 5 Vdc (TTL) Input (32 Points)

IC697MDL652 12 Vdc Input, Positive/Negative Logic (32 Points)

IC697MDL652CA 12 Vdc Input, Positive/Negative Logic (32 Points) Conformal coated.

IC697MDL652RR 12 Vdc Input, Positive/Negative Logic (32 Points)

IC697MDL653 24 Vdc Input, Positive/Negative Logic (32 Points)

IC697MDL653RR 24 Vdc Input, Positive/Negative Logic (32 Points)

IC697MDL654 48 Vdc Input, Positive/Negative Logic (32 Points)

IC697MDL654RR 48 Vdc Input, Positive/Negative Logic (32 Points)

IC697MDL671 Interrupt Input Module, 14 points

IC697MDL671RR Interrupt Input Module, 14 points

IC697MDL740 24/48 Vdc Output, 2 Amp, Positive Logic (16 Points)

IC697MDL740RR 24/48 Vdc Output, 2 Amp, Positive Logic (16 Points)

IC697MDL750 24/48 Vdc Output, 0.5 Amp, Positive Logic (32 Points)

IC697MDL750RR 24/48 Vdc Output, 05 Amp, Positive Logic (32 Points)

IC697MDL752 12 Vdc Output, 0.5 Amp, Positive Logic (32 Points)

IC697MDL752CA 12 Vdc Output, 0.5 Amp, Positive Logic (32 Points) Conformal Coated

IC697MDL752RR 12 Vdc Output, 05 Amp, Positive Logic (32 Points)

IC697MDL753 5/48 Vdc Output, 0.5 Amp, Negative Logic (32 Points)

IC697MDL753RR 5/48 Vdc Output, 05 Amp, Negative Logic (32 Points)

IC697MDL940 Relay Output, Signal, 2 Amp (16 Points)

IC697MDL940RR Relay Output, Signal, 2 Amp (16 Points)

IC697MEM713 Expansion RAM, 64K Bytes, CMOS (Used w/77X CPUs and PCM)

IC697MEM713RR Expansion RAM, 64 KBytes, CMOS (Used w/77X CPUs & PCM)

IC697MEM715 Expansion RAM, 128K Bytes, CMOS (Used w/77X CPUs and PCM)

IC697MEM715RR Expansion RAM, 128 KBytes,CMOS (Used w/77X CPUs & PCM)

IC697MEM717 Expansion RAM, 256K Bytes, CMOS (Used w/77X CPUs and PCM)

IC697MEM717RR Expansion RAM, 256 KBytes,CMOS (Used w/77X CPUs & PCM)

IC697MEM719 Expansion RAM, 512K Bytes, CMOS (Used w/77X CPUs and PCM)

IC697MEM719RR Expansion RAM, 512 KBytes,CMOS (Used w/77X CPUs & PCM)

IC697MEM731 Expansion RAM, 128K Bytes, CMOS, 32 Bit (Used w/78X CPUs)

IC697MEM731RR Expansion RAM, 128K Bytes, CMOS, 32 Bit (Used w/78X CPUs)

IC697MEM732 Exp. RAM, 256K Bytes, Non-volatile Flash, 32 Bit (Used w/78X CPUs)

IC697MEM732RR Exp RAM, 256K Bytes, Non-volatile Flash, 32 Bit (Used w/78X CPUs)

IC697MEM733 Expansion RAM, 256K Bytes, CMOS, 32 Bit (Used w/78X CPUs)

IC697MEM733RR Expansion RAM, 256K Bytes, CMOS, 32 Bit (Used w/78X CPUs)

IC697MEM735 Expansion RAM, 512K Bytes, CMOS, 32 Bit (Used w/78X CPUs)

IC697MEM735RR Expansion RAM, 512K Bytes, CMOS, 32 Bit (Used w/78X CPUs)

IC697MLX000 Series 90-70 Labels Kit

IC697MSC701RR Series 90-70 Demonstration Case

IC697MSC800 GMR Redundancy System, 386, 100 TMR  I/O, (Rack, P/S, CPU, RAM, 3-GBC)

IC697MSC801 GMR Redundancy System, 386, 2K TMR  I/O, (Rack, P/S, CPU, RAM, 3-GBC)

IC697MSC802 GMR Redundancy System, 486, 2K TMR  I/O, (Rack, P/S, CPU, RAM, 3-GBC)
