5730032-FH ABB

From: | author:kongjiang | Release :2021-08-05 | 134 view: | Share:

5730032-FH    ABB

Extension XK 08 F1

 The common C of inputs has to be linked to the 0 V or 24 V d.c. according to the sensor type.



Extension XO 08 Y1

The 24 V DC power supply used for the loads should be linked to the 0 V or 24 V DC terminals situated on the top or bottom terminal blocks. These terminals are linked internally, therefore it just requires linking one 0 V and one 24 V DC terminals

Warning: In the case of the terminal 0 V is disconnected and in the same time the 24 V DC is connected, the leakage current on output is 16 mA.

Extension XO 08 R2

Extension with 4 relay NO and 4 relay NO/NC

The connection terminals named C0, C1, C2, C3, C4, C5, C6, and C7 are independent.


Cabling the analog central extensions

Extension XM 06 B5

 The extension is powered with 5 V by the basic unit or the remote unit. The connection between the extension and the basic unit is effectuated with the cable situated on the left side of the extension.

 Warning: The extensions must be connected or disconnected without power supply.
