101935-217 ABB

From: | author:kongjiang | Release :2021-08-05 | 118 view: | Share:

101935-217    ABB

 The basic and remote units may be connected at any point of the system bus:  - bus 1 on bus 1

-bus 2 on bus 2

-shielding (preferably braided) on terminal 3 of terminal block 1 and earth connected atthe master level (cable < 0.1 m)

 The system bus should be terminated with a 120 Ω 1/4 W resistor connected to the bus ends. The twisted pair should be symmetrical.



 Connecting the system bus shielding to the earth is recommended, with the intercalation of a 1 nF class Y condenser directly at the cabinet entry, according to the assembly diagram, if noise generating devices are near to the cabinet.

 As the CS31 system bus is opto-isolated, it is possible to place elements with different voltage power on the bus.

 Refer to the respective descriptions if a bus amplifier or amplifier with bus redundancy is used.
