101935-203 ABB

From: | author:kongjiang | Release :2021-08-05 | 122 view: | Share:

101935-203    ABB

Earthing principles for several cabinets

 When the cabinets are close to each other the different earths should be connected together using a cable with a cross section of at least 16 mm².

 The noise generating devices (actuators, motors, etc.) should not be earthed in-between two cabinets. The earthing should be done near to the element causing the most disturbance.



Cabling of the CS31 system bus

 The CS31 system bus is a RS-485 serial interface and consists of a shielded twisted pair. This bus is a master/slave bus and only accepts a single master.

 Use a AWG 24 (0.22 mm2) to AWG 18 (0.18 mm2) twisted pair.

 The maximum length is 500 m.

 The same cable type should be used for the whole system bus setup.

 Bus interruptions should be avoided, during cabinet cable connections for instance, otherwise it should be cabled to the same side of the terminal block.



 Warning: STAR connection of the system bus is not permitted!
