S800 I/O is a comprehensive, distributed and modular process I/O system that communicates with parent controllers over industry-standard field buses. Thanks to its broad connectivity it fits a wide range of process controllers from ABB and others. By permitting installation in the field, close to sensors and actuators, S800 I/O reduces the installation cost by reducing the cost of cabling. And thanks to features such as “hot swap” of modules, “on-line” reconfiguration and redundancy options, it contributes to keeping production – and thereby profits – up.

Advant Fieldbus 100. Twisted pair screened/coaxial/fiberoptic cable. Up to 79 stations per bus. Up to 32 per twisted-pair segment. Bus length: Up to 750m (2 460ft.) per twisted-pair segment overall up to: 15km (9.3 miles). Profibus DP. Twisted pair screened/fiber-optic cable. Up to 99 stations per bus. Up to 32 per twisted-pair segment. Bus length: Up to 1200m (3937ft.) per twisted-pair segment.

I/O modules with intrinsic-safety interface

 DI890 digital inputs with wire-fault detection 8 ch., separate returns, 24V d.c., current sink.

DO890 digital outputs with wire-fault detection 4 ch., separate returns, load 150-5000Ω, 11V @ 40mA, current source, short circuit-proof.

AI890 Analog inputs. 8 ch., single-ended, 0(4)-20mA, 12 bits, transmitter power supply

AI893 TC/RTD inputs. 8 ch., TC: 7 + ref. junction, sep. returns. TC types B, C, E, J, K, L, N, R, S, T, U, -10…80mV. RTD: Pt50-1000, Ni100-500, Cu10- 100, resistor 0-4000Ω, 3-wire. 15 bits + sign.

AI895 with intrinsic safety & HART interface 8 ch., single-ended, 4-20mA, 12 bits, transmitter power supply.

AO890 with intrinsic safety & wire-fault detection 8 ch., common return, 0(4)-20mA, 12 bits, load: 750Ω (short-circuit-proof).

AO895 with intrinsic safety, HART interface & wirefault detection. 8 ch., common return, 4-20mA, 12 bits, load: 750Ω (short-circuit-proof)

Analog input modules

AI810 8 channels, single-ended, 0(4)-20mA, 0(2)-10V, 12 bits.
