2VAA005447R030 ABB H&B Contronic

2VAA005447R030    ABB H&B Contronic

Interfaces

Transmission standard between the central unit ca. 6 ms

and input/output modules EIA RS–485 (ABB Procontic CS31 system bus)

Bus transmission time

LED indicators 323 µs

Input signals 1 yellow LED per channel

Bus Error 1 red LED

Overload (and short–circuit) 1 red LED (lights up, if there is an overload or a short–circuit at the supply voltage on at least at one input channel)

Supply 1 green LED (lights up, if the supply voltage is > 18 V)

Mechanical data

Degree of protection according to DIN 40040, IEC 529 IP 65

Dimensions (length x width x height) 247.5 x 78.5 x 78.06 mm

Mounting dimensions 236.5 x 49 mm or 236.5 x 43 mm

Weight ca. 0.75 kg

Ordering data Order No.

Input module ICPI 08 D1 GJV 307 56 14 R0101

Accessories:

5–pole M12 plug, male, ”straight” GJV 307 56 17 R1

5–pole M12 plug, male, ”bended” GJV 307 56 18 R1

4–pole M12 plug, male, ”straight” GJV 307 56 21 R1

4–pole M12 plug, male, ”bended” GJV 307 56 22 R1

M12 filler plug GJV 307 56 19 R1
