In order to meet the Degree of Protection IP65, suitable cables with certain diameters must be used at the cable glands (bus, I/O connectors, supply voltage): cable diameters for bus and I/O 4.5 mm to 6.5 mm, for supply voltage 5 mm to 10 mm. The electrical specifications for the bus cables can be found under the CS31 system data.

Intended purpose

The binary output module ICPO 08 H1 is a remote module on the CS31 system bus. It has 16 binary channels with the following features:

 Housing and termination system according to IP65 degree of protection

 The CS31 bus line is looped through from module to module. For this purpose, the module has two bus connectors as bus input and bus output.

 Each output has its own connector and thus can be unplugged individually.

 The 24 V DC supply voltage is connected via screw–type terminals inside the module housing.
