8VZZ000853L325    ABB H&B Contronic

● Serial interface COM2 as an  MMC interface

● Additional interface for connecting communication mo-dules (e.g. 07 KP 90)

● Real-time clock

● LEDs for displaying the binary input and output signalsas well as operating conditions and error messages

● Detachable screw-type terminal blocks

● Detachable plastic sheet on the front side of the device ;can be labelled with the signal names in order to have the inputs and outputs directly assigried

● Fastening by screws or by snapping the device on a DINrail

● The lithium battery 07 LE 90 can be put into the battery

compartment in order to

– store and back-up the user program in the RAM

– store and back-up data which is additionally containedin the RAM, e.g. the status of flags

– back-up the time and date (real-time clock)

● RUN/STOP switch for starting and aborting the programexecution

● Extensive diagnosis functions

– Self-diagnosis of the central unit

– Diagnosis of the ABB Procontic CS31 system bus andthe connected modules

additionnal positioning modules, slave central units as well as input and output modules.

The main features of the 07 GV 93 positioning module are :

● 1…3 axes

3BSC690073R1

DI890 Digital Input IS 8 ch

3BSC690074R1

DO890 Digital Output IS 4 ch

3BSC690075R1

TU890 IS MTU

3BSC740007R1

Main Supply Filter 250V, 20A

3BSC740008R1

Main Supply Filter 250V, 55A

3BSC740009R1

Main Supply Filter 250V, 80A

3BSC840074R1

TC506 AF 100 Trunk Tap

3BSC840157R1

TU891 non-IS MTU

3BSC910044R1

Mounting Plate 24"

3BSC910048R1

Mounting plate 19"
